Spektrum - Item No. SPMSS7110
4.8 out of 5 Customer Rating

S7110 Low Profile Servo Winch: 1/10 Rock Crawlers

$159.99
RC Club points earned on this item shown at checkout.
  • (1) S7110 High Voltage Servo Winch
  • (1) Scale recovery hook
  • (1) Aluminum spool
  • (1) 7’ Fiber line

Features

  • Design for 1/10th Scalers and Crawlers
  • 6V to 8.4V Operating Voltage
  • Durable and long-lasting brushless motor
  • High Torque (130oz-in @ 6V, 160oz-in @ 7.4V, and 180 oz-in @ 8.4V)
  • All Aluminum servo case for heat dissipation
  • 7' feet of line with scale recovery hook included
  • Built-in Integrated brushless controller for easy set up and installation
  • Precise metal internal gears
  • Waterproof
  • 25 teeth output shaft
  • Includes everything needed to start winching

Overview

The Spektrum servo winch offers incredible performance for 1/10th scaler and crawlers. High voltage capable, the servo winch can produce 160 oz of torque at 155RPM at 7.4V input. It's low-wear, metal gear drive train is powered b a brushless motor and bearing supported for smooth operation. Like all Spektrum servos, the S7110 Servo Winch delivers reliability, consistency, and performance that is second to none.

PRODUCT SPECS

Current Draw Stall
1.6A @ 6.0V, 1.8A @ 7.4V, 2A @ 8.4V
Servo Operating Voltage
6.0 - 8.4V (HV)
Programmable
No
Prop 65
Prop 65 Warning Icon  California Residents Prop 65 WARNINGS.
Servo Size Category
Low Profile
Product Weight
2oz (57g)
Spline Count
25 - Tooth
Bearing
Ball Bearing
Bushing Or Bearing
Bearing
Gear Type
Metal
Wire Gauge
22 AWG
Connector Type
Universal
Maximum Servo Speed
123RPM @ 6.0V, 155RPM @ 7.4V
Product Length
1.59" (40 mm)
Rotation Range
360 Degree Continuous
Connector Wire Length
7.48" (190 mm)
Current Draw Idle
2mA
Product Width
0.8" (20 mm)
Maximum Servo Torque
130oz/in @ 6.0V, 160oz/in @ 7.4V, 180oz/in @ 8.4V
Input Voltage
6.0V ~ 8.4V
Product Height
0.99" (25 mm)
Servo Type
Digital
Application
1/10 Rock Crawlers- Winch
