Posted: 1/9/18
Found in: YETI SCORE TROPHY TRUCK / YETI / RR10 BOMBER
Stock Gearing
Yeti: 32P 16T Pinion / 64T Spur Gear
Yeti SCORE Trophy Truck: 32P 16T Pinion / 64T Spur Gear
RR10 Bomber: 32P 12T Pinion / 64T Spur Gear
Gearing Chart
32 Pitch (Stock Gearing AX30392 or AX30395)
_
Spur Gear
Pinion
56
60
64
68
11
28.85
30.91
32.97
35.03
12
26.44
28.33
30.22
32.11
13
24.41
26.15
27.90
29.64
14
22.67
24.28
25.90
27.52
15
21.15
22.67
24.18
25.69
16
19.83
21.25
22.67
24.08
17
18.67
20.00
21.33
22.67
32 Pitch (Overdrive Gearing AX30401)
_
Spur Gear
Pinion
56
60
64
68
11
25.38
27.19
29.00
30.81
12
23.26
24.92
26.58
28.25
13
21.47
23.01
24.54
26.07
14
19.94
21.36
22.79
24.21
15
18.61
19.94
21.27
22.60
16
17.45
18.69
19.94
21.18
17
16.42
17.59
18.77
19.94
32 Pitch (Underdrive Gearing AX30402)
_
Spur Gear
Pinion
56
60
64
68
11
25.38
34.97
37.31
39.64
12
29.92
32.06
34.20
36.33
13
27.62
29.59
31.57
33.54
14
25.65
27.48
29.31
31.14
15
23.94
25.65
27.36
29.07
16
22.44
24.04
25.65
27.25
17
21.12
22.63
24.14
25.65
AXIAL YETI SCORE TROPHY TRUCK / YETI / RR10 BOMBER
AXA0413 M2.6x8mm Hex Screws
AXA1045 M4 Nylon Locking Hex Nuts
AXA1221 Bearing 5x11x4mm
AXA1391 E4 E-clips
AXA144 M3x8mm Flat Head Screws
AXA0147 M3x16mm Flat Head Screws
AXA148 M3x18mm Flat Head Screws
AXA150 M3x25mm Flat Head Screws
AX30163 Pin 2.0x10mm
AX30413 Slipper Spring
AX31059 Slipper Plate Washer
AX31065 Spur Gear 23P 64T
AX31067 Slipper Plate
AX31068 Slipper Pads
AX31106 2-Speed Hi/Lo Transmission Motor Mount
AX31107 2-Speed Hi/Lo Transmission Spur Gear Cover
AX31108 2-Speed Hi/Lo Transmission Case
AX31127 2-Speed Hi/Lo Transmission Top Shaft
AX31129 2-Speed Hi/Lo Transmission Bottom Shaft
AX31130 High Speed Transmission Gear Set
AX31131 T-Case Gear Set
AX31180 Aluminum Spur Gear Spacer
AX31313 Transfer Case Output Shaft
AX31324 RR10 Transfer Case
